DOM の鋼鉄管

Din 2391 High Pressure Bright Annealing Seamless Precision E235 Steel Tube 1. DIN2391 high precision bright seamless steel pipe Made of Baosteel's high-quality carbon steel material, after precise drawing, non-oxidative bright heat treatment (NBK state), non-destructive testing, the inner hole of the steel pipe is subjected to high-pressure washing and pickling, the inner and outer walls of the steel pipe are treated with anti-rust oil, and both ends are sealed as Dust-proof

Products Description TORICH High Tensile Thin Wall 34mm MS 1010 Plastic End Caps for AISI 1020 46mm 4130 Carbon Seamless Mild ASTM A513 1026 DOM Tube Quick Detail: Honed steel pipes is used for hydraulic Cylinders and oil and pnuematic Cylinders.with material E155 E195 E235 E275 E355. Raw material steel pipes as per stamdard EN10305-2, Cold drawn ERW steel pipes , Cold drawn seamless pipes. Feature 1.Honed Hydraulic Cylinder Tube is made from DOM steel tubes,With high

Products Description BS6323-6 35mm Wall Thickness Seamless Welded Steel Tubes DOM Steel Tubes Machining Material CEW1a CEW2a CEW3a CEW4a CEW5a Size WT: 1-35mm; OD: 6-350mm; Length: max 12m Production Method Seamless Cold Drawing Or Cold Rolling/Electric Resistance Welded Applications For Auto Industry / For Machinery Use/mechanical And General Engineering Purposes Test Flattening test, Drift expanding test, Leak tightness test. Method of Manufacture: The tubes are manufacture

Product Description Torich Motorcycle Steel Tube EN10305-2 Welded Precision Cold Drawn DOM Steel Tube EN10305-2 DOM Pipe for Motorcycle Shock Absorbers Basic detail information 1. Grade:E155 E195 E235 E275 E355 2. Size: O.D.:6-350mm W.T.:1-35mm L:max12000mm 3. Standard: EN10305-2 4. Certification: ISO9001, ISO14001,TS16949 5.Applications: for Auto industry/for machinery use/Oil Cylinder Tube/Motorcycle shock absorber Auto shock absorber inner cylinder/Telescopic Cylinders 6

Products Description: ASTM A512 1020 1030 Cold Drawn Steel Pipe Buttweld Carbon Steel Tube Steel Grade: 1008, 1010, 1012, 1015 etc Size Range: OD: 5-88.9mm WT: 0.89-12.7mm Length: max12000mm Our regularproduction size 25.4*2.11mm, 50.8*2.11mm Chemical Component: Steel Grade C Mn P max S max 1008 ≤0.10 0.30-0.50 0.040 0.045 1010 0.08-0.13 0.30-0.60 0.040 0.045 1012 0.10-0.15 0.30-0.60 0.040 0.045 1015 0.13-0.18 0.30-0.60 0.040 0.045 1016 0.13-0.18 0.60-0.90 0.040 0.045 1018 0

TORICH BS 6323-4 CFS 3/ CFS 3A/ CFS 4 Round Seamless DOM Steel Tube Product Description: OD: 5-220 mm WT: 0.5-25mm Length: Max 7000mm Delivery Condition: 1 BK Cold finished(hard) 2 BKW Cold finished(soft) 3 GBK Annealed 4 NBK Normalized 5 GZF Annealed (including de-scaling) 6 NZF Normalized (including de-scaling) DOM Steel Tube Production Process: Raw material → Incoming inspection → Cutting → Heating → Piercing → Hammering →Pickling → Cold-drawing → Heat treatment → Physical

TORICH BS6323-6 Cold Finished Electric Resistance Welded DOM Steel Tube Product Description: Standard: BS6323-6 Size Range: OD: 6-350mm WT: 1-35mm Length: max 12000mm Steel Grade: CEW1a CEW2a CEW3a CEW4a CEW5a Delivery Condition: 1 BK Cold finished(hard) 2 BKW Cold finished(soft) 3 GBK Annealed 4 NBK Normalized 5 GZF Annealed (including de-scaling) 6 NZF Normalized (including de-scaling) Product Pictures: Packing: Characteristic: Good concentricity Good OD and ID tolerance

TORICH SAE J526 DOM Low-Carbon Seamless Steel Tube Product Description: SAE J526 DOM Carbon Seamless Steeel Tube: Products Description: 16X1 20X2 DIN2391 ST35 CDS DOM Steel Tube DIN2393 ST35 CDW DOM Steel Tube DOM Steel Pipe Steel Grade/Steel Material: E155,E195,E235,E275,E355 Delivery Condition: BK, BKW, BKS, GBK, NBK Size Range: OD: 4.0-420mm WT:0.5-50mm Length: max 12000mm Our regularproduction size 60x50 42x3.2mm Characteristic: Good concentricity Good OD and ID tolerance

EN10305 ASTM A519 Grade E355 DOM Cold Drawn Welded Tube for Hydraulic Cylinder ID : 30--250mm ID Tolerance : H8 H9 Grade: 20# 45# 16Mn 25Mn 27SiMn E355 SAE1026 Standard: GB/T8713 GB/T3639 DIN2391 EN10305 ASTMA519 Range: 30-300mm Length: 11m(max) Tolerance on Wall Thickness: Diameter: >40 +/-0.2mm Diameter: 40 100 +/-0.5mm Processing : cold drawn cold rolled honed SRB Burnish Delivery condition of hydraulic cylinder tube: 1.NBK(+N) of hydraulic tube after cold forming,
