ASTMの合金鋼の等級のInconelの管、抗張特性のInconelよい625の管

基本プロパティ
原産地: 中国
ブランド名: Torich
認定: CE PED
モデル番号: Inconel 625
取引物件
最低注文数量: 1000 kg
価格: 6000-20000 USD per ton
支払条件: L / C、T / T
供給能力: 1 年ごとの 200 トン
製品概要
インコネル鋼管は,合金鋼級インコネル625で製造されます. 化学成分:最大% C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al:≤0.40 Ti:≤0.40 Nb:3.15-415 Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07 物理常数: 密度0.305g/cc で44 材料の特徴: 耐腐食性が優れている 酸化抵抗性 低温から980°Cまでの良好な拉伸性能 低温から980°Cまでの良好な耐疲労性能 インコネル 625機械的特性 種類 張力特性 持続的なパフォーマンス 硬さ θ/°C σb/MPa ...

製品詳細

ハイライト:

Inconel 600 の管

,

inconel 718の管

Material: 625
Standard: ASTM B444
OD: 1-450mm
Production Method: 冷たい-引き分け
Type: 継ぎ目が無い
MTC: En10204.3.2B
製品説明

インコネル鋼管は,合金鋼級インコネル625で製造されます.

化学成分:最大%

C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al:≤0.40 Ti:≤0.40 Nb:3.15-415

Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07

物理常数:

密度0.305g/cc で44

材料の特徴:

耐腐食性が優れている

酸化抵抗性

低温から980°Cまでの良好な拉伸性能

低温から980°Cまでの良好な耐疲労性能

インコネル 625機械的特性

種類 張力特性 持続的なパフォーマンス 硬さ
θ/°C σb/MPa σP0.2/MPa δ5/% θ/°C σ/MPa t/h δ5/%
より大きい より大きい
バール1 20 830 410 30 815 114 23 15 HB≤290
表2 20 830 410 30 815 114 23 15 HV≤305
バー 20 830 410 30 Q/3B 4078-1992 年 -
シート 20 825 415 30 Q/3B 4077-1992 年 -
パイプ 20 825 415 35 Q/3B 4080-1992 年 HRC≤25

1 標準 Z9-0105-1990. 2 標準 Z9-0104-1990 と GJB 3317-1998.

標準:

管規格:ASTM B444 ニッケル・クロム・モリブデン・コロンビア合金 (UNS N06625とUNS N06852) とニッケル・クロム・モリブデン・シリコン合金 (UNS N06219)

ASTM B622 シームレスニッケルとニッケル・コバルト合金管とチューブ

プレート・シート規格:ASTM B443 ニッケル・クロム・モリブデンコロンビア合金(UNS N06625 と UNS N06852) とニッケル・クロム・モリブデン・シリコン合金 (UNS N06219)プレート,シート,ストリップ

鍛造:ASTMB564 ニッケル合金鍛造.

航空機エンジン部品,海水用,エンジン排気システム,燃料および水力管管の適用.
