溶接された鋼鉄管

Exhaust pipes aluminized Steel Tube for Exhaust System Product name: Aluminized Steel Tube for Exhaust System Keyword:aluminized steel pipe,aluminized exhaust pipe,aluminized steel exhaust pipe,aluminized steel tube Group: welded steel tube Standard:JIS G3445-2006, EN10130 material: SA1D, DC04, etc. Size range:OD,5-420mm,WT,0.5-50mm,Length, max 12m Application:Exhaust system Technique: ERW Surface:coating with aluminum 80g/120g price:8000-9000RMB/ton MOQ:10tons Deliver time

Double Wall Galvanized Bundy Tube WithZinc Coating For Automobile Brake 1. Standard GM123M, GM124M, TS7600G, GB 11258-89 2. Steel Grade/Steel Material/Steel Number: Low carbon steel, such as SPCCBLDBLC 3. Raw Material: Cold rolled low carbon steel strip 4. Characteristic: Good Surface Quality, Uniform coating No coating burr Stable quality Excellent corrosion resistance TORICH QUALITY ASSURANCE 5. Application: Brake tube on automobile 6. Specifications: OD(mm) OD tolerance(mm

TORICH GM123M GM124M Galvanized Double Wall Bundy Tube With Zinc Coating For Automobile Brake 1. Standard GM123M, GM124M, TS7600G, GB 11258-89 2. Steel Grade/Steel Material/Steel Number: Low carbon steel, such as SPCC BLD BLC 3. Raw Material: Cold rolled low carbon steel strip 4. Characteristic: Good Surface Quality, Uniform coating No coating burr Stable quality Excellent corrosion resistance TORICH QUALITY ASSURANCE 5. Application: Brake tube on automobile 6. Specifications

TORICH SAEJ526 PVF/Copper Coating Single Wall Bundy Tube For Brake system 1. Standard SAEJ526 Welded low-carbon tubing EN10305-6 Welded cold drawn tubes from hydraulic and pneumatic power systems ASTM A254 Copper-brazed steel tubing 2. Steel Grade BHG1,SPCC,SPCD, SPCEN, ST14, ST15, ST16,DC04, DC05, DC06 3. Heat Treatment BK or NBK 4. Specification O D/ mm 4 4.2 4.76 6 6.35 7.8 8 9.52 W T 0.5-1.0mm (0.5-0.7mm common WT) Tolerance ±0.05mm Length 180Kg/coil; 700-1000m/coil; per

TORICH EN10305-2 E155,E195,E235,E275,E355 Welded Cold Drawn DOM Steel Tubes Steel Grade/Steel Material: E155 E195 E235 E275 E355 Delivery Condition: 1 BK Cold finished(hard) 2 BKW Cold finished(soft) 3 BKS Cold finished and stress-relieved 4 GBK Annealed 5 NBK Normalized Size Range: O.D.:6-350mm W.T.:1-35mm L:max12000mm Characteristic: Good concentricity Good OD and ID tolerance High precision Stable quality Smooth roughness DOM Steel Tube Production Process: Raw material →

SAE J526 Carbon Welded Steel Tube Mechanical Coil Tubing for Auto Spec: Material:C Si Mn P S Size Range:OD:3.18-18mm WT:0.5-1.2mm General Length:1-200m Tolerance: According to the following tables or customers’ request. Table 1 Outer diameter, wall thickness and theoretical weight OD/mm WT/mm 0.30 0.40 0.50 0.60 0.65 0.70 0.80 0.90 1.00 1.30 theoretical weight /(kg/m) 3.18 0.0213 0.0274 0.0330 4.00 0.0274 0.0355 0.0432 0.0503 4.76 0.0330 0.0430 0.0525 0.0616 0.0659 0.0701 5

EN10217-1 P235TR1 P195TR1 Carbon Steel Welded Pipe For Pressure Purposes EN10217-1 Welded steel tubes for pressure purposes - Technical delivery conditions - Part 1: Non-alloy steel tubes with specified room temperature properties Since 2nd century, the welding seam quality increased a lot with fast development of excellent quality steel coil production, welding technology and inspection technology improvement, more welding steel tube sizes are available, and gradually widely

SAE J526 Welded Automotive Fuel Steel tube Application:covers welded single-wall low-carbon steel tubing intended for generalautomotive, refrigeration, hydraulic, and other similar applications requiring tubing of a quality suitable forbending, flaring, beading, forming, and brazing. size:length--2~12m WT--2~4.5mm OD--16~50mm Manufacture:The tubing shall be made from a single strip of steel shaped into a tubular form, the edges ofwhich are joined and sealed by a suitable

SAE J526 Welded Low Carbon Steel tube for Automotive Fuel Line High Pressure Oil Tubes for Diesel Engine Galvanized Precision Tube , NBK Precision Steel Tube , Passivated Steel Tubes High Pressure Oil Tubes for Diesel Engine Production process: Cold drawing bright heat treatment without oxidization 100%nondestructive testing inside flushing under the high pressure antirust oiling outer and inner surface. Main Features: high accuracy, excellent brightness, no oxidization on
