ニッケル-基礎超合金の鋼管 Incoloy A - 286 7.94 G/Cm の ³ の合金鋼鉄管

基本プロパティ
原産地: 中国
ブランド名: Torich
認定: CE PED
モデル番号: 合金の鋼管 Incoloy A-286
取引物件
最低注文数量: 1000 kg
価格: 交渉可能
支払条件: L / C、T / T
供給能力: 1 年ごとの 200 トン
製品概要
合金鋼パイプ インコローイA-286 材料の特徴: 化学成分: C: ≤0.08 Cr:13.5-16.0 ニ:24.0-27.0 モ:1.00-1.50 Ti:1.75-2.30 Fe:残ったV:0.10-0.50B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020 Fe-25Ni-15Crベース超合金 + モリブデン,チタン,アルミニウム,バナジウム 物理的特性: 密度 7.94 g/cm3 0.287 lb/in3溶融点 1430°C 2600°F膨張係数 16.4 μm/m °C (20 - 100°C) 9.1 ...

製品詳細

ハイライト:

合金鋼鉄管

,

合金鋼鉄継ぎ目が無い管

製品説明

合金鋼パイプ インコローイA-286

材料の特徴:

化学成分:

C: ≤0.08 Cr:13.5-16.0 ニ:24.0-27.0 モ:1.00-1.50 Ti:1.75-2.30 Fe:残ったV:0.10-0.50B:0.001-0.010 Mn:1.00-2.00 Al ≤0.04 Si:≤1.00 P:≤0.030 S:≤0.020

Fe-25Ni-15Crベース超合金 + モリブデン,チタン,アルミニウム,バナジウム

物理的特性:

密度 7.94 g/cm3 0.287 lb/in3
溶融点 1430°C 2600°F
膨張係数 16.4 μm/m °C (20 - 100°C) 9.1 x 10-6 イン / イン °F (70 - 212°F)
硬度モジュール 71.5 kN/mm2 10370 ksi
弾性電極 205 kN/mm2 29733 ksi

インコローイA-286熱処理

材料の種類 熱処理
バー パイ 980~1000°C,1~2h,オイルクーラー+700~720°C,12~16h,エアクーラー
ホットロールシート,冷たいロールプレート 980~1000°C 空気冷却+700~720°C 12~16h 空気冷却
冷たく引き寄せた棒 980~1000°C,1~2h オイルクーラー+700~720°C,16h エアクーラー
リング・ブランク 980~990°C,1~2h オイルクーラー+700~720°C 16h エアクーラー
冷たい方向 冷たい引き出物 980~1000°C,水または油冷却+700~720°C,16h,空気冷却

高性能 耐久性

クリープ強度

加工の可塑性と溶接性能が良好

インコローイA-286は航空宇宙分野で使用されています.

関連規格:

SAE AMS5731 耐腐食・耐熱鋼,バー,ワイヤー,鍛造物,チュービング,リング 15Cr-25.5Ni-1.2 Mo-2.1Ti

SAE AMS 5732 鋼,耐腐蝕性,耐熱性,バー,ワイヤー,鍛造物,チュービング,リング15Cr - 25.5Ni - 1.2Mo - 2.1Ti - 0.006B - 0.30VC消費電極 溶解と降水 熱処理 1800°F (982°C)

AMS 5737

AMS 5525

類似のガード:UNSS66286 (アメリカ),ZbNCT25 (フランス),PQA286 (アメリカ)
