質 16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 工場

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile

Name: 16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile
Brand: TORICH INTERNATIONAL LIMITED
SKU: 16MnCr5
Price: 2,550.00 USD
Availability: InStock

基本プロパティ

原産地: Zhejiang/China

ブランド名: TORICH

認定: ISO9001 ISO14001 TS16949

モデル番号: 16MnCr5

取引物件

最低注文数量: 1トン

価格: 交渉可能

支払条件: L/C,D/A,D/P,T/T,Western Union,MoneyGram

供給能力: 年間60000トン/トン

タグ

16MnCr5 Carbon Steel Seamless Pipe: Case Hardening Steel Tube for Automobile Material Specification 16MnCr5 is a low-alloy steel known for its excellent case hardening properties, making it an ideal choice for automotive applications. This steel grade is widely used in the manufacturing of seamless ...

製品詳細

ハイライト:

ケース硬化炭素鋼のシームレスパイプ

,

16MnCr5 炭素鋼のシームレスパイプ

,

自動車用炭素鋼のシームレスパイプ

Mtc: EN 10084

Secondary Or Not: Non-secondary

Thickness: 0.5-100mm

Technical: 冷たい-引き分けの継ぎ目が無い

Special Pipe: 冷たい精密継ぎ目が無い管-引かれる

Material: Steel

Inner Diameter: Customized

Heat Treatment: +C, +LC, +SRA, +A,+N

Surface Finish: Oiled

Country Of Origin: Zhejiang,CN

Origin: Zhejiang, China

Technology: 熱く巻き冷たく巻き

Application: Automobile

Standard: ASTM、DIN、GB、JIS、API

Certification: API,CE,ISO,ISO9001-2008,ISO9001

Technique: Cold Drawn,Hot Rolled,Cold Rolled,

Surface Treatment: カスタマイズした

Grade: 16MnCr5

Alloy Or Not: Is Alloy

Section Shape: 丸い,長方形

Outer Diameter(Round): 17 - 660 mm

Special Pipe: Thick Wall Pipe,API Pipe,Precision steel tube,precision seamless pipe,cold drawn

Length: 6M or as requirement,As customer's require,

Product Name: steel tubes,Cold drawn precision round carbon steel tube,Stainless steel seamless pipe 304 304l 316 316l,Seamless Steel Pipe,Good quality weld cold drawn hydraulic cylinder precision steel tube

Type: Seamless,Welded,welded or seamless tube,

製品説明

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 0

16MnCr5 Carbon Steel Seamless Pipe: Case Hardening Steel Tube for Automobile

Material Specification

16MnCr5 is a low-alloy steel known for its excellent case hardening properties, making it an ideal choice for automotive applications. This steel grade is widely used in the manufacturing of seamless pipes and tubes, which are essential components in the automotive industry due to their strength, durability, and wear resistance.

Key Features

High Wear Resistance: The case hardening process enhances the surface hardness, providing excellent wear resistance.
Good Toughness: Retains toughness and ductility in the core, ensuring durability under stress.
Machinability: Offers good machinability, allowing for precision manufacturing.
Versatility: Suitable for a variety of applications, especially in the automotive sector.

Chemical Composition

The chemical composition of 16MnCr5 is crucial in determining its properties. Below is a table presenting its typical chemical composition:

Element	Composition (%)
Carbon (C)	0.14 - 0.19
Silicon (Si)	0.17 - 0.37
Manganese (Mn)	1.00 - 1.30
Phosphorus (P)	≤ 0.025
Sulfur (S)	≤ 0.035
Chromium (Cr)	0.80 - 1.10

Mechanical Properties

The mechanical properties of 16MnCr5 are essential for its performance in automotive applications. The table below outlines its typical mechanical properties:

Property	Value
Tensile Strength	800 - 1100 MPa
Yield Strength	≥ 420 MPa
Elongation	≥ 10%
Hardness (HB)	150 - 220

Similar Standards and Steel Grades

16MnCr5 is comparable to several international standards and steel grades, making it a versatile choice for global applications. Below are some equivalent standards:

ASTM: A29/A29M
EN: 1.7131
GOST: 20MnCr5
JIS: SCM415
GB: 20MnCr5

Application

16MnCr5 seamless pipes and tubes are primarily used in the automotive industry, where they serve as critical components in the manufacturing of gears, shafts, and other parts that require high surface hardness and core toughness. Their ability to withstand wear and tear makes them suitable for high-stress environments, ensuring longevity and reliability in automotive applications.

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 1

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 2

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 4

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 6

16MnCr5 Carbon Steel Seamless Pipe Case Hardening Steel Tube For Automobile 7
