welded steel pipe
"
冷間圧延ASTM A513はDOMの生産の鋼鉄管を溶接しました
ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing Size: 10-350mm Applications: for machinery, mechanical enginee 1. Standard: ASTM A513 cold rolling welded precision steel tubes 2. Steel Grade: SAE1010, SAE1020, other materials upon agreement with customers. 3. Production method: Cold rolling on the weled steel tubes, to reach high accuracy on the OD and WT tolerance 4.Size range: O.D.:6-350mm W.T.:1-15mm L:max12000mm 5. Packing: In Hexagonal
自動車部品のための円形のアルミニウムで処理された溶接された鋼鉄管OD127mm*WT1.5mm
OD127mm*WT1.5mm Aluminized Welded Steel Tubes,steel grade SPCC/SPHC from TORICH ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing Size : O.D.:6-350mm W.T.:1-12.5mm L:max12000mm Grade: 1010, 1020, 1026 Production: ERW + DOM Steel Grade and Chemical Compositions: Steel Grade C Mn P S Si Cr Mo max max max max min 1008 0.10 0.5 0.035 0.035 1010 0.08-0.13 0.30-0.60 0.035 0.035 1018 0.14-0.20 0.30-0.60 0.035 0.035 1020 0.17-0.23 0.30-0.60 0.035 0.035
鉱山の液体サービスのためのGB/T 14291 Q235AのQ235Bによって溶接される鋼鉄管
Welded Steel Tubes for Mine Liquid Service GB/T 14291 Q235A Q235B Spec: Material:Q235A Q235B Q345A Q345B Size Range:OD:4-1200mm WT:0.3-200mm General Length:4-12m Tolerance: According to the following tables or customers’ request. TABLE 1 Mechanical Property Grade Tensile strength N/m Lower yield strength / N/m Elongation A% Not less than D≤168.3 D＞168.3 Q235A,Q235B 375 235 15 20 Q295A,Q295B 390 295 13 18 Q345A,Q345B 470 345 13 18 Note : Tensile test arbitration time is based
鉱山の液体サービスGB/T 14291 Q235A Q235Bのための溶接された鋼鉄管
Welded Steel Tubes for Mine Liquid Service GB/T 14291 Q235A Q235B Spec: Material:Q235A Q235B Q345A Q345B Size Range:OD:4-1200mm WT:0.3-200mm General Length:4-12m Tolerance: According to the following tables or customers’ request. Table 3 Outer Diameter,Wall Thicknes,Theoretical Weight and Test Pressure Norminal Outer Diameter(D)/mm Norminal Wall Thickness(S)/mm Theoretical Weight/(kg/m) Test Pressure/MPa Q235A,Q235B Q295A,Q295B Q345A,Q345B 21.3 2.5 1.16 15 15 15 21.3 3 1.35
ASTM A787は鋼鉄管0.71Tの炭素鋼の機械管のマフラーの管を溶接しました
ASTM A787 Welded 0.71T Carbon Steel Mechanical Tubing Muffler Pipe Standard Specification of ASTM A787 Tubing Specification covers round, square, rectangular, and special shape, electric-resistance-welded mechanical tubing, either zinc-coated (galvanized) after welding or produced from aluminum-coated, zinc-coated (galvanized), zinc-iron alloy-coated (galvannealed), 55 % aluminum-zinc alloy-coated, or zinc-aluminum-magnesium alloy-coated steel sheet. Tubing for use as
耐久の風邪-引かれた溶接された鋼鉄管のガスばねの支柱はGB/T 33156を配管します
Cold Drawn Welded Steel Tube Gas Spring Strut Pipes GB/T 33156 Products Description Quick Detail: Product name GB/T 33156 Welded Cold Drawn Steel Tubes Gas Spring Strut Pipes Steel Grade E155, E195, E235, E275, E355 Size Range OD range:15-200mm WT range: 0.8-16mm Tolerance OD: (+/-0.06mm) WT: (+/-0.03mm) ID surface 0.4μm Straightness ≤0.5mm/1m Roundness ≤0.5mm Regular specifications 23.2X1.6, 42X3, 25.4X0.9, 15x1, 19x1.5, 20x1, 20x1.5 Delivery Condition +C, +LC, +SC, +A, +N
正方形の鋼管の空セクション鋼鉄管のあたりで溶接されるQ195 Q235 Q345 ERW
Q195 Q235 Q345 ERW Welded Round Square Steel Pipe Hollow Section Steel Tube Production: Steel pipe / steel tube Standard: API 5L, ASME, ASTM B36, JIS, DIN, GB8162, GB8163, GB5310, etc. Material: ASTM A106 GRB/ A53 GRB/ API 5L X42, X52, X60, X65, X70GRB/ API 5 CT/ Q345/ ST42/ST37/ ST52. Q195/Q215/Q235/A179etc. Out Diameter: DN10~DN1200, 1/8"~100", 6mm~2400mm Wall Thickness: SCH5~SCH160, STD, XS, XXS, 1mm~120mm Length: 12m, 11.8m, 6m, 5.8m, or as customers required Surface
Erwの円形のQ235によって溶接される鋼鉄管は、Erw塗られた鋼管Gb/t9711-2011 Psl1を黒くします
GB/T9711-2011 PSL1 Round Pipe Chart of Weight ERW Q235 Welded Steel Tube ERW Casing Pipe GB/T9711-2011 PSL1 Round Pipe Chart of Weight ERW Q235 Welded Steel Tube ERW Casing Pipe Standard: GB/T9711-2011 PSL1,GB/T9711-2011 PSL2 GB/T3091-2008,API SPEC.5L PSL1,API SPEC.5L PSL2, API SPEC.5CT Grade: J55, K55, N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr, C90, T95, P110,Q125 Size: Tubing : 2 3/8", 2 7/8", 3 1/2", 4", 4 1/2“ Casing : 4 1/2", 5", 5 1/2", 6 "5/8", 7&
Astm A523は高圧のための端の継ぎ目が無い溶接された管/Erwの鋼管を嘆きます
Products Description TORICH ASTM A523 Plain End Seamless and ERW Steel Pipe for High-Pressure Product Name Plain End Seamless and ERW Steel Pipe for High-Pressure Standard ASTM A523, A370, A751, E59, ANSI B36.10 Techinique Electric Resisitance Welded Type Seamless and Welded Test Flattening Test, Hydrostatic Test Coatings The pipe shall not be given a mill coating of paint, oil, or any other material either inside or outside Application High Pressure pipe-type electric cables
