seamless alloy steel pipe
"
16MnCr6 20MnCr5 20CrMn の合金の鋼管、風邪-引かれた継ぎ目が無い鋼鉄管 TS16949
Alloy Steel Tubes and Pipes 16MnCr5 20MnCr5 20CrMn Alloy steel grade 20MnCr5 equivalent to 20CrMn Steel Tubes with alloy steel grade 20MnCr5: 16MnCr5 C:0.14-0.19, Mn:1.00-1.30, P≤0.035, S≤0.010-0.050, Cr:0.80-1.10, Si≤0.40 20MnCr5 C:0.17-0.22, Mn:1.10-1.50, P≤0.035, S≤0.10-0.050, Cr:1.00-1.30, Si≤0.25 20CrMn C:0.17-0.23, Mn: 0.90-1.20, Cr:1.00-1.30, Si:0.17-0.37 Mechanical Properties: Tensile strength: min 885Mpa Yield strength: min 685Mpa Elongation: min 12% Hardness: max
冷たい-引かれた継ぎ目が無い合金鋼の管は表面1000-1200 mmの長さに油をさしました
Product Description TORICH ASTM A519 AISI4130 AISI4140 Seamless Alloy Steel Tubes Standard ASTM A519 Matrial AISI4130 AISI4140 Size OD: 6-350mm WT: 1-50mm Length: 1-12m Manufacture Tubes are made by seamless process. At the manufacturer's option, tubing may be furnished either hot finished or cold finished. Condition Sizing Methods 1. Hot-Finished Mechanical Tubing 2. Cold-Worked Mechanical Tubing 3. Rough -Turned Mechanical Tubing 4. Ground Mechanical Tubing Thermal
低密度の合金鋼の管重量10.2-4.5 Mmの、石油化学製品のためのチタニウムの継ぎ目が無い管
Products Description TORICH GB/T 3624 Low Density Titanium Alloy Steel Tube For Petrochemical/Automobile Key Word Titanium Alloy Steel Tube Material TA1,TA2,TA3,TA8,TA8-1,TA9,TA9-1,TA10 Size OD: 4-114mm; WT: 0.2-4.5; Length: 1-12m Application Aerospace, petrochemical, shipbuilding, automobile, medicine etc. Mechanical Porperties Alloy Grade Tensile strength /Mpa specified non-proportional extension strength /Mpa percentage elongation after fracture % TA1 ≥240 140-310 ≥24 TA2
機械冷たい働かせた合金鋼管は AISI4130 AISI4140 をアニールしました
Alloy steel 4130 4140 for ASTM A519 seamless steel tubes ASTM A519 SEAMLESS STEEL TUBES, by DOM production, with the steel grade of SAE4140 and SAE4130, other alloy steel grade upon customer's agreement.: SAE4130: C: 0.28-0.33% Mn: 0.40-0.60% P max 0.40% S max 0.40% Si: 0.15-0.35% Cr: 0.80-1.10% Mo: 0.15-0.25% SAE4140: C: 0.38-0.43% Mn: 0.75-1.00% P max 0.40% S max 0.40% Si: 0.15-0.35% Cr: 0.80-1.10% Mo: 0.15-0.25% Sizing Method: 1. HF- hot finished 2.CW-cold worked Themal
熱処理を用いる注文34crmo4合金鋼の管の丸型1 - 12m
TORICH 34CrMo4 Alloy Steel Tubes Material:34CrMo4 Chemical composition: C:0.30~0.37 Si:0.10~0.40 Mn:0.60~0.90 S:permissible residual content ≤0.035 P:permissible residual content ≤0.035 Cr:0.90~1.20 Ni:permissible residual content ≤0.030 Cu:permissible residual content ≤0.030 Mo:0.15~0.30 Mechanical properties: Tensile strength σb (MPa):≥985(100) Yield strength σs (MPa):≥835(85) Elongation δ5 (%):≥12 rate of reduction in area ψ (%):≥45 Impact energy Akv (J):≥63 Impact
発電のために引かれるAstm A213-2001の合金鋼の管の継ぎ目が無い風邪-
ASTM A213-2001 Cold Drawn Seamless Alloy Steel and Pipe alloy steel and pipe Material : Titanimu Alloy Steel, Characteristic of the material:High strength ,low density,good mechanical property ,good tenacity.good corrosion resistance . It can be made by seamless and welded.and widely apply in power generation,Aerospace,oil and gas ,chemical processing. Available size list: OD 6-127mm WT: 0.5-10mm Cold drawn Seamless pipes with Ti and Ti alloy grade condition Diameter/mm Wall
チタニウムの石油化学製品/自動車のための合金鋼の管GB/T 3624の低密度
GB/T 3624 Titanium and Titanium Alloy Steel Pipe Material :TA1,TA2,TA3,TA8,TA8-1,TA9,TA9-1,TA10. Characteristic of the material:High strength ,low density,good mechanical property ,good tenacity.good corrosion resistance . Titanium and Titanium Alloy Steel Pipe Size : OD 4-114mm WT0.2-4.5mm Application: Aerospace, petrochemical, shipbuilding, automobile, medicine.etc. Chemical component: Steel Grade Nominal Chemical Composition Chemical Composition/% Main components Impurity
機械304 306のための溶接された継ぎ目が無い合金鋼の管ASTM A554
ASTM A554 Welded Stainless Steel Tubing for Mechanical 304 306 Name stainless steel pipe Items Square tubes, round tubes, oval pipes, special shaped pipes, empaistic pipes, fittings Standard ASTM A554, A249, A269 and A270 Material Grade 201: Ni 0.8%~1% 202: Ni 3.5%~4.5% 304: Ni 8%, Cr 18% 316: Ni 10%, Cr 18% 316L: Ni10%~14% 430: Cr16%~18% Outer Diameter 9.53mm--159mm Thickness 0.3mm - 3.0mm Length 6m or as customers' request a) Outer Diameter: +/- 0.2mm Tolerance b) Thickness
GB/T19447熱交換器のための継ぎ目が無い合金鋼の管/合金鋼のひれ付き管
Products Description TORICH GB/T19447 C10200 Copper Alloy Steel Pipe Fin Tube with Integral Fins for Heat Exchanger Material C10200, C11000 Etc Size Fin Thickness: 0.1-2mm; Tube OD: 8-55mm; Length: max 12m Fin Pitch Customize Surface Copper Coated End protector Plain End / Beveled End Application Oil&Gas Well Drilling, For Heat Exchanger Test Tension Test, Flaring Test, Flange Test, Reverse Test, Hardness Test, Hydrostatic or Nondestructive Electric Test Quick Detail: Low
