cold formed steel tube
"
チタニウム/チタニウムの合金の構造スチールの管は高力鋼片を禁止します
ASTM B348 Gr1 UNS R50250 Gr2 UNS50400 Gr5 UNS56400 Titanium and Titanium Alloy Bars and Billets Material : Titanimu Alloy Steel Product name Titanium and Titanium Alloy Bars and Billets Standard ASTM B348, E8, E29, E539, E1409, E1447, E1941, E2371, E2626 Steel Grade Gr1 (UNS R50250) Gr2 (UNS50400) Gr5 (UNS56400) Gr6 Gr9 Gr12 etc Production Hot rolled, forged, extruded or Cold worked Characteristic of the material:High strength ,low density,good mechanical property ,good
交通機関のための電流を通されたDIN 2440 EN10255によって通される溶接された継ぎ目が無い鋼管
Good Quality DIN2440 EN10255 Seamless Steel Pipe for Transportations The pipe follow the DIN2440 EN10255 is for circular non- alloy steel tubes suitable for welding and threading and provides a number of options for the finish of tube ends and coatings. This standard covers tubes of steel outside diameter 10.2mm to 1651mm (thread size 1/8 to 6) in two series, medium and heavy, and three types of designated thicknesses. Medium-weight threaded steel tubes Application: air,
17 - 114mm の外径が付いている GOST 3262-75 水/ガスの構造スチールの管:
GOST 3262-75. Water-supply and Gas-supply Steel Pipes Outside Diameter: 17 – 114 mm Nominal Diameter: 10, 15, 20, 25, 32, 40, 50, 65, 80, 90, 100 mm Wall Thickness: light: 2 – 4 mm; medium: 2,2 – 4,5; heavy: 4,5 – 5 mm. Steel Grades – 08kp, 08ps, 10, 15, 15kp, 15ps, 20, 20kp, 20ps, St1sp, St1ps, St2sp, St2ps, St3kp, St3ps, St3sp Random length: 4 – 9 m, fixed length: 6 – 8 m. The pipes are delivered without zinc-coating, thread and couplings, of normal precision Sizes Nominal
ASTM A106 A53 API 5L の構造スチールの管、炭素鋼の継ぎ目が無い管
Structural Steel Pipe , ASTM A106 A53 API 5L Seamless Carbon Steel Tubing ASTM A106 A53 API 5L Seamless carbon steel tubes for high temperature service Applications: for high temperature service Size range: O.D.:6-168mm W.T.:1-15mm L:max12000mm Steel Grade and Chemical Compositions: Steel Grade C Mn P S Si Cr Cu Mo Ni V max max max min max max max max max A 0.25 0.27~0.93 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 B 0.30 0.27~1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 C 0
GOST 30245の鋼鉄建築構造のための長方形の空セクション構造スチールの管
Rectangular Hollow Sections GOST 30245Steel bent closed welded square and rectangular section for building Application:for steel Building Structures. Manufacture method:Shaping the round tubular section with longitudinal weld(Automatic high frequency welding) and consequent spellerizing to square or rectangular section. The article sections shall conform to those specified in fingures 1 and 2 Remark: h—Height(width)；b—width；t—wall thickness；R—edge radius；I—Inertia moment；W
ステンレス鋼の構造管、継ぎ目が無い空の構造スチールの管
ASTM A847 Cold Drawn Seamless Low Alloy Square/Rectangular Structural Pipes Size range: O.D.: 6-813mm W.T.:1-12.7mm L: according to customer requirement Steel Grade and Chemical Compositions: Steel Grade and Chemical Compositions C≤ Mn≤ P≤ S≤ Cu≥ 0.24 1.40 A 0.06 0.80B Mechanical Properties: Tensile strength min Mpa 483 Yield strength min Mpa 345 Elongation min % 19A Manufacture: Tubes are made by seamless process. The tubing may be stress relieved or annealed, as is
ノズルの化学注入の液体システムのための10*2 12*1の狭量な管
10*2 **1 12*1 Small Bore Tubing For Nozzle Chemical Injection Liquid System Quick detail: Standard:EN 10305-1 DIN2391 Material: E235 E355 1010 1020 10# 20# St37 St42 etc Size: 4-12mm WT:05-7mm Description: Chemical composition of EN 10305-1 Steel Grade C Si Mn P S Al Steel name Steel number max max max max max min E215 1.0212 0.10 0.05 0.70 0.025 0.025 0.025 E235 1.0308 0.17 0.35 1.20 0.025 0.025 - E355 1.0580 0.22 0.55 1.60 0.025 0.025 - Mechanical and techological
溶接された高力低合金の構造スチールの管ASTM A847材料
ASTM A847 Welded High-Strength Low Alloy Structural Pipes Size range: O.D.: 6-1626mm W.T.:1-15.88mm L: according to customer requirement Steel Grade and Chemical Compositions: Steel Grade and Chemical Compositions C≤ Mn≤ P≤ S≤ Cu≥ 0.24 1.40 A 0.06 0.80B Mechanical Properties: Tensile strength min Mpa 483 Yield strength min Mpa 345 Elongation min % 19A Manufacture: Tubes are made by welded process. Welded tubing shall be made from flat-rolled steel by the electric-resistance
庭の建物および橋100*50*5*7のための溶接された構造の構造スチールの管Hのビーム
100*50*5*7 Welded Construction Used H Beam H Beam Steel for Garden building and Bridge Construction Size : 100*50*5*7-912*302*18*34 Standard : GB, JIS, EN, ASTM, DIN, AISI, BS, etc Technique : Hot-rolled and welded according to your requirement Grade : Q195-Q235, Q345, ASTM A36, ASTM A572, SS400 Length : 12m or customized Delivery Time : 10-20 days after receving prepayment or according to order quantity Packing : packed in bundles, Shipped by container or bulk vessal Payment
